DC mV

600.0mV
  ±1.5%rdg ±3dgt

直流钳形传感器

60.00/200.0A (自动量程)
  ±1.5%rdg ±3dgt + 传感器精确度

AC V

6.000/60.00/600.0/1000V (自动量程)
  ±1.0%rdg ±3dgt [40 - 500Hz] (6/60/600V)
  ±1.3%rdg ±3dgt [40 - 500Hz] (1000V)

AC mV

600.0mV
  ±2.0%rdg ±3dgt [40 - 500Hz]

交流钳形传感器

60.00/200.0A (自动量程)
  ±2.0%rdg ±3dgt + 传感器精确度 [40 - 500Hz]

Ω

600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ   (自动量程)
  ±0.5%rdg ±4dgt (600Ω)
  ±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ)
  ±1.5%rdg ±3dgt (40MΩ)

导通蜂鸣

600Ω (低于90Ω蜂鸣器鸣叫)

二极管测试

开环电压: < 3.0V

电容测试

60.00/600.0nF/6.000/60.00/600.0/1000μF
  ±2.0%rdg ±5dgt (60/600nF)
  ±5.0%rdg ±5dgt (6/60/600/1000μF)

频率

99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg   ±3dgt

DUTY

10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz]

安全规格

IEC 61010-1 CAT IV 300V / CAT III 600V   / CAT II 1000V
  IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS)

电池

R03 (1.5V) × 2

外形尺寸

155(L) × 75(W) × 40(D)mm

重量

250g Approx. (含电池)

附件

翼型支架
  7066A (测试线)
  R03 × 2, 使用说明书

可选件

7234 (鳄鱼夹测试线)
  8161 (AC 钳形传感器)
  8115 (AC/DC 钳形传感器)
  9189 (磁性挂钩)
